HoloAudio – Bliss Headphone Amplifier

General info:

LINE IN:

Single-ended RCA input

Maximum amplitude 8.4Vrms
Input impedance 6.2KΩ

Balanced XLR input

Maximum amplitude 16.8Vpp
Input impedance 12.4KΩ

HEADPHONE

OUTPUT:
4P XLR Output

Low impedance mode (LO-Z): Output impedance 0Ω, power 12Wrms@32Ω
High impedance mode (HI-Z): output impedance 15Ω, power 2.5Wrms@150Ω

4.4mm Pentaconn Output

Low impedance mode (LO-Z): output impedance 2Ω, power 12Wrms@32Ω
High impedance mode (HI-Z): output impedance 17Ω, power 2.5Wrms@150Ω

6.35mm TRS Output

Low impedance mode (LO-Z): output impedance 1Ω, power 3Wrms@32Ω
High impedance mode (HI-Z): output impedance 8.5Ω, power 0.6Wrms@150Ω

LINE OUT:

Single-ended RCA Output

Maximum amplitude 10Vrms
Output impedance 20Ω

Balanced XLR Output

Maximum amplitude20Vrms
Output impedance 40Ω

Standard Bliss = 2998$

KTE Bliss = 3398$

Download Manual:

click here to download HoloAudio Bliss Manual
